Clamp Flange Lavatory Spring Hinges 1000-Series

Clamp Flange Lavatory Spring Hinges 1000-Series

SKU: CFSpgHingeLav

Description

Lavatory Hardware
Single Acting Spring Hinges

01001 – 1001 SERIES

1001 CLAMP FLANGE FOR DOOR AND JAMB

01001 CLAMP FLANGE FOR DOOR AND JAMB

  • BRASS MATERIAL
  • NON-HANDED
  • AVAILABLE WITH HOLD OPEN ( 1001-H )
  • AVAILABLE FOR DOORS AND JAMBS 7/8″ TO 1 3/4″ THICK
  • EASILY ADJUSTABLE SPRING TENSION ON 1001 MODEL
  • NO SPRING ON THE 01001 MODEL
  • SPECIFY DOOR AND JAMB THICKNESS FOR PROPER CLAMP FLANGE SIZING
  • THRU BOLTS AND ONE WAY SCREWS STANDARD

Product Specifications

ITEM NUMBERHINGE HEIGHTDOOR THICKNESSJAMB THICKNESSHOLD OPENBOX QTYCASE QTYCASE WT
1001 4" 7/8" - 1 3/4" 7/8" - 1 3/4" NO 1 ea. 16 ea. 40 lbs.
1001-H 4" 7/8" - 1 3/4" 7/8" - 1 3/4" YES 1 ea. 16 ea. 40 lbs.
01001 2" 7/8" - 1 3/4" 7/8" - 1 3/4" NO 1 ea. 16 ea. 20 lbs.

Template Files
