Non-UL – 4 1/2″ Template 4020-Series

Non-UL – 4 1/2″ Template 4020-Series

SKU: non-ULTemplate

Description

Single Acting Spring Hinges

4000 SERIES

4020 STEEL
STANDARD 4 1/2″ MORTISE TEMPLATE
ANSI K81071

  • NON-HANDED
  • STEEL MATERIAL
  • AVAILABLE WITH REVERSE SPRING
  • EASILY ADJUSTABLE SPRING TENSION
  • PIVOT POINTS DO NOT ALIGN WITH STANDARD FULL MORTISE BUTT HINGES

Product Specifications

ITEM NUMBER 2 HINGES MAX DOOR WT 2 HINGES MAX DOOR WIDTH 3 HINGES MAX DOOR WT 3 HINGES MAX DOOR WIDTH DOOR THICKNESS WOOD SCREWS MACHINE SCREWS # OF HOLES BOX QTY CASE QTY CASE WT
4020-6 125 lbs 3'-0" 155 lbs 4'-0" 1 3/4" 12 X 1 1/4 12-24 X 1/2 8 2 ea. 12 ea. 32 lbs
